Features and Advantages
High-viscosity fluid dispensing Jetting force increased by 20%, and can handles high-viscosity adhesives (up to 500000mPa·s).
Convenient maintenance Uses new design of top calibration and nozzle position fixation, improved the stability of dispensing and convenience of processing maintenance.
Precision glue control Faster development time (0.01ms), more accurate control of dispensing process parameters and stable control of ultra-small glue volumes.
Online correction of process parameter Supports quick online switching of 10 channel parameters amd seamless parameter transitions through I/O interface based on process needs.
Application Fields
技术规格
| Type | KPS6000 |
| Input Air Pressure | 0.1 - 8bar |
| Adhesive Viscosity | 1 - 500000mPas |
| Min. Amount Of Dispensing | 0.5nl (CPK>1.33, water as the testing medium) |
| Max. Dispensing Frequency | 1200Hz |
| Dimension (W*D*H) | 123*121*28.7mm (with KHM3500 heating module) / 123*91*28.7mm(w/o heating module) |
| Weight | 602g (with flow channel component) |
| Work Temperature | 10 - 50℃ |
| Main Functions | Nozzle calibration-free and top calibration |
| Quick release of tappet rod and flow channel | |
| Detection and alarm of valve temperature | |
| High-temperature monitoring of controller | |
| Certification Standard | ROHS |
Applicable Fluid
