Features and Advantages
Ease of operation 3D import: The dispensing trajectory is quickly generated
by importing the product 3D diagram.
Real-time display of dispensing trajectory: The dispensing trajectory path is always consistent with the product
overturning posture, improving the convenience of
programming
Efficiency improvement Double-station design: The left and right stations work
alternately to save the loading and unloading time.
Back-to-back design: Dispensing operation and glue path
inspection are carried out synchronously.
Quality control 3D inspection: Online glue path inspection is realized by line scanning laser.
Achievement of high-quality and high-precision
dispensing 3D guidance: The dispensing trajectory is automatically
generated by line laser scanning of the product to ensure
the dispensing accuracy.
Position comparison mode: The uniform transition of the
arc dispensing is realized by means of frequency
conversion.
Solving of incoming material consistency problem Visual edge grabbing: Precise control of dispensing position is realized by feature point position compensation.
Meeting information management requirements Docking with MES system to upload the production
status information in real time and give an alarm and
trace in case of any abnormity.
Supporting CCD Mark positioning function and CCD
programming.
Core Modules
3D Vision Module
3D guidance: The dispensing trajectory is automatically generated by line laser scanning of the product to ensure the dispensing accuracy
3D inspection: Online glue path inspection is realized by line scanning laser
Dispensing Detection Execution Module
Back-to-back design: Dispensing operation and glue path inspection are carried out synchronously to improve the operation efficiency
Double-Station Module
The double stations work alternatively to improve the operation efficiency
Automatic Loading & Unloading Module
Unmanned loading and unloading are realized by automatic picking + handling to save the labor costs
